UL Listed D810 Deadbolt - UL 3 Hours Fire Rating Certified, ANSI / BHMA E8211 Auxiliary Lock Standard
Home >
Products > Auxiliary Lock > LUTER D810 Single Cylinder and Thumbturn Auxiliary Moritse Deadbolt
LUTER's D810 Thumbturn Moritse Deadbolt cannot only be used in storage and shaft, but also can assort with our FL Series Cylindrical Lever / FA Series Knob lockset, it's high security and multi-function product.
| Face plate: | SUS 304, Satin Stainless steel, 142mm(L) x 25mm(W) |
| Backset: | 70mm |
| Deadbolt: | 1" throw Stainless steel deadbolt with a built in hardened steel pin |
| Thumb turn: | Stainless steel 304 |
| Cylinder: | Mortise cylinder, Interchangeable Core |
| Keyway: | Schlage E, Schlage C, Yale, BEST, L6 (65M/006) |
| Finish: | US32D, PVD+US32D, US32, US26, US3, US5 or other request |
Exploded View
